    27 X 96 Inch Galvanized Metal Rib Lath Corner Protection With ASTM A653 Standard

    Ask Lasest Price
    Brand Name : X MESH
    Model Number : X MESH-Rib Lath 002
    Certification : ISO9001:2015
    Price : USD6.15-35.85/PC
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 19850m2/week
    Delivery Time : 5-7days
    • Product Details
    • Company Profile

    27 X 96 Inch Galvanized Metal Rib Lath Corner Protection With ASTM A653 Standard

    27 X 96 Inch Galvanized Metal Rib Lath Corner Protection with ASTM A653 Standard

    Rib Lath Introduction:

    Rib lath is expanded metal-lath stiffened with longitudinal ribs.
    The furring design of the mesh provides efficient background plaster for construction of partition,
    suspended ceilings and refurbishment works. The advantage of ribbed-lath over metal-lathing is that support centers can be increased or widened.

    Product Name

    Rib Lath

    Material

    Pre-galvanized mild steel

    Sheet Thickness

    0.35mm

    Rib Distance

    100mm

    Weight

    2.09kgs/pc

    Width

    610mm

    Length

    2440mm

    Feature

    Firm & Stable

    Application

    For Building

    Packing

    Plastic film & Pallet Packing

    Rib Lath Standard Specification:

    Model

    Thickness(mm)

    Weight(kg)

    Width(mm)

    Length(mm)

    Rib Height (mm)

    Rib Distance(mm)

    021

    0.21

    1.70

    450

    2200

    14-20

    90

    023

    0.23

    1.90

    450

    2200

    14-20

    90

    030

    0.30

    2.48

    450

    2200

    14-20

    90

    035

    0.35

    2.90

    450

    2200

    14-20

    90

    040

    0.40

    3.30

    450

    2200

    14-20

    90

    045

    0.45

    3.70

    450

    2200

    14-20

    90

    050

    0.50

    4.10

    450

    2200

    14-20

    90



    Type

    Sheet thickness
    (mm)

    Rib Distance
    (mm)

    Weight
    (kg)

    WidthXLength
    (mm)

    7830

    0.30

    100

    1.79

    610X2440

    7835

    0.35

    100

    2.09

    610X2440

    7840

    0.40

    100

    2.38

    610X2440

    7845

    0.45

    100

    2.68

    610X2440

    7850

    0.50

    100

    2.98

    610X2440

    Type

    Sheet thickness
    (mm)

    Rib Distance
    (mm)

    Weight
    (kg)

    WidthXLength
    (mm)

    7430

    0.30

    100

    1.26

    610X2440

    7435

    0.35

    100

    1.49

    610X2440

    7440

    0.40

    100

    1.68

    610X2440

    7445

    0.45

    100

    1.89

    610X2440

    7450

    0.50

    100

    2.11

    610X2440

    Type

    Sheet thickness
    (mm)

    Rib Distance
    (mm)

    Weight
    (kg)

    WidthXLength
    (mm)

    9430

    0.30

    75

    1.89

    610X2440

    9435

    0.35

    75

    2.28

    610X2440

    9440

    0.40

    75

    2.53

    610X2440

    9445

    0.45

    75

    2.84

    610X2440

    9450

    0.50

    75

    3.15

    610X2440

    Type

    Sheet thickness
    (mm)

    Rib Distance
    (mm)

    Weight
    (kg)

    WidthXLength
    (mm)

    5830

    0.30

    150

    1.31

    610X2440

    5835

    0.35

    150

    1.53

    610X2440

    5840

    0.40

    150

    1.75

    610X2440

    5845

    0.45

    150

    1.96

    610X2440

    5850

    0.50

    150

    2.17

    610X2440

    Lath Standard:

    • ASTM A653

    • ASTM A924

    • ASTM C841 (Installation)

    • ASTM C847

    • ICC ESR-1623

    • Fed. Spec. QQ-1-101C

    • ANSI A42.3, ANSI A42.4

    • U.S. HUD 4930.1

    Rib Lath Feature:

    1. Rib Lath Mesh is the perdurable board mesh combined to the concrete, it is strong to the joint gap.
    2. The Rib Lath Mesh need not to be backouted after the finishing concrete.
    3. The Rib Lath Mesh is easy to be cut, , to be made into any shape, to be transported, especially for the working in high condition.
    4. It has the ability of resisting very cold or hot weather, it will not fall or change shape.
    5. The coarse surface arises on the joint of mesh boards, this will provide very ideal joint surface for the next moulding.
    6. The board mesh is derectly fastened to the reinforcing steel bar, so it can save much time, material and manpower...
    7. The last Rib Lath Mesh will stay on the surface of the concrete, it will reinforce the concrete, prevent the concrete from shrinking and avoid the gap.
    8. It does good to the protection of the environment, makes the building site keep clean.

    Rib Lath Application:

    It is widely used in big-scale building, such as tunnel, bridge, basis, cloaco, subway. Holding wall, nuclear power electricity factory, boatyard, high building, oceanic building, irregular building. And so on.
