Highway Galfan Powder Coated AS/NZS 4534-2006 Standard 358 Security Mesh Fencing

358 Security Mesh Fencing Description:

358 Welded Anti Climbing Fence – Prison Mesh Fencing

358 anti climb fence, known as "prison mesh", is a high security anti-climbing and anti-cutting welded wire fence. Galvanized wire, commonly, is welded into fencing panels with extremely fine opening holes, which cannot be penetrated by hand fingers or cut by bolt cutters. Therefore it is highly recommended for high security needed area and private living field.

The name—358 high security fence comes from the size of panel mesh opening and wire diameter: 3'' × 0.5'' × 8 gauge, approximately equals to: 76.2 mm × 12.7 mm × 4 mm. As a welded wire fence, galvanized after welded and then PVC coated is recommended for a sturdy structure and corrosion resistance ability.

358 Security Mesh Fencing Introduction:

• Wire: 4 mm steel wire.

• Wire surface finish: galfan coating after welded, and then PVC powder coating (Min. 120 micron), or PVC powder painting.

• PVC coated color: black, dark green, brown, yellow, desert sand, bronze or other colors request.

• Mesh opening pattern: 70 mm × 8 mm, welded well at each intersection.

• Mesh sheet width: 2515 mm.

• Anti-climb mesh fencing panels and posts.

• Fence security toppings: Flat razor wire coils with barbed wire, concertina barbed wire, security fence spikes, or shark tooth spikes (coating according to the anti-climb fence panels).

  • Shark tooth spikes: width 35 mm, long teeth up to 58 mm.

  • Security anti-climb fence spikes:

    • Plate thickness: 2.0 mm

    • Base width: 65 mm.

    • Spike length: 35 mm short spikes, 70 mm long spikes.

    • Spikes pitch: 70 mm.

  • Razor wire

    • Style: flat razor wire or concertina razor wires.

    • Barb length: short barb or long barb.

    • Material: galvanised steel, stainless steel (for extremely corrosive environments).

    • Wire: high tensile 25 mm, aluminum/zinc wire, breaking load 7700 N.

    • Coil Diameter: 600 mm, 750 mm.

    • Number of loops: 55.

    • Extent length: 7.5 m.

  • Barbed wire

    • Galvanized and PVC coated barbed wire with 2 strands and 4 points.

    • Gauge of strand and barb wire: 11 gauge.

    • Barbs spacing: 3 inch.

358 Security Mesh Fencing Specification:

Wire Panels: 3" x 0.5" x 10.5ga (8' ht.) / 8ga (10' ht.) anti-climb mesh

Impasse II Rails: 2"sq x 11ga

I-Beam Posts: 3" x 2.75" x 12ga / 4" x 2.75" x 12ga

Heights: 8' & 10'

358 Security Mesh Fencing Feature:

• Anti-Cut and Anti-Climb Security

• Single Sided Installation

• Groundable Fence Solution Meeting IEEE Standards

• Integrated Design

• IBC Compliant Options Available

• PermaCoat Maintenance Free Finish

• Meets Buy American Act

• 10 Year Limited Warranty

358 Security Mesh Fencing Packaging:

358 mesh fence panels packed in wooden pallets and enveloped by plastic film then wrapped by tape firmly for the security of storage and transportation.

358 Security Mesh Fencing Application:

• Prison perimeter areas.

• Military sites and government facilities.

• Electricity distribution sites.

• Airports, railways, roadways.

• Seaports.

• Fencing & intrusion detection projects.

• Hydel power project.

• Petroleum and chemical facilities.

• Wildlife sanctuaries.

• Warehousing facilities,

• School.

​​
