KxT Brown Vinyl Coated Chain Link Fence

    Buy cheap KxT Brown Vinyl Coated Chain Link Fence from wholesalers

    Buy cheap KxT Brown Vinyl Coated Chain Link Fence from wholesalers
    • Buy cheap KxT Brown Vinyl Coated Chain Link Fence from wholesalers
    • Buy cheap KxT Brown Vinyl Coated Chain Link Fence from wholesalers

    KxT Brown Vinyl Coated Chain Link Fence

    Ask Lasest Price
    Brand Name : X MESH
    Model Number : X MESH-015
    Certification : ISO9001:2015
    Price : USD1.25-5.85/m2
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 50000m2/week
    Delivery Time : 5-7days
    • Product Details
    • Company Profile

    KxT Brown Vinyl Coated Chain Link Fence

    Brown Vinyl KxT Selvage residential ASTM F668 Standard chain link mesh fencing

    chain link mesh fencing Introduction:

    chain link mesh fencing, Although galvanized silver chain link fences are very popular, many customers have chosen color chain link fence systems to accentuate siding, roofing, and trim colors on houses and businesses. There are two types of vinyl coating(PVC coating) based on the thickness: extruded and adhered and fused and bonded. Dark green(RAL 6005) chain link fence is the most popular one among a lot of colors. Extruded and bonded chain link, always refer to as 'heavy' vinyl chain link fence is also an option.

    Extruded vinyl coated chain link fence is by far the most popular kind of chain link fence available in colors. It is typically the least expensive too. However, some quality conscious customers also prefer fused and bonded fence fabric.

    chain link mesh fencing Physical Properties:

    Nominal coated

    wire diameter

    Available variance

    Zinc coating weight, min.

    Breaking strength
    minimum

    Class 1

    Class 2

    ga

    inch

    mm

    inch

    mm

    oz/ft2

    g/m2

    oz/ft2

    g/m2

    lbf

    Newtons

    6

    0.192

    4.88

    +/- 0.005

    +/-0.13

    1.20

    366

    2.00

    610

    2,170

    9,650

    9

    0.148

    3.76

    +/- 0.005

    +/-0.13

    1.20

    366

    2.00

    610

    1,290

    5,740

    11

    0.120

    3.05

    +/- 0.005

    +/-0.13

    1.20

    366

    x

    x

    380

    1,690

    chain link mesh fencing Specification:

    A typical specification list for 9 gauge chain link fence fabric

    PVC Coated Chain Link Fence - 9 Gauge

    PVC Coated
    9 gauge

    *Colors depicted not exact

    Size
    (Mesh x Gauge x Height)

    Ends

    Weight
    Per 50'

    2 x 9 x 36

    KxK

    53 lbs

    2 x 9 x 42

    KxK

    63 lbs

    2 x 9 x 48

    KxK

    70 lbs

    2 x 9 x 60

    KxK

    88 lbs

    2 x 9 x 72

    KxB

    105 lbs

    2 x 9 x 84

    KxB

    123 lbs

    2 x 9 x 96

    KxB

    140 lbs

    2 x 9 x 120

    KxB

    173 lbs

    2 x 9 x 144

    KxB

    208 lbs

    1-3/4 x 9 x 120

    KxB

    198 lbs

    1-3/4 x 9 x 144

    KxB

    238 lbs

    1. Gauge of wire is 'finish size' inclusive of vinyl coating in this instance;

    2. Meets ASTM F 668-04, Class 1, thickness of polymer coating between 0.015 - 0.025 inch(0.38 - 0.64mm).

    chain link mesh fencing packaging:

    1.Woven bags of the above and bottom, high quality package or as customers requested.
    2.In roll, waterproof paper in side and our side with weave bag; carton; wooden case; pallet.
    3. According to client's requirement.

    chain link mesh fencing Application:

    chain link mesh fencing has many applications including residential housing fences, building site and factory enclosures, sporting field enclosures, temporary fencing, internal factory partitions and more.chain link mesh fencing has many applications including residential housing fences, building site and factory enclosures, sporting field enclosures, temporary fencing, internal factory partitions and more.
