    150 X 150mm Hole Size 3660mm Height Security Metal Fencing Welded

    Ask Lasest Price
    Brand Name : X MESH
    Model Number : X MESH-Welded Razor Mesh-06
    Certification : ISO9001:2015
    Price : USD25.00-75.00/Set
    Payment Terms : T/T, Western Union, L/C, MoneyGram
    Supply Ability : 5000sets/week
    Delivery Time : 5-8days
    • Product Details
    • Company Profile

    150 X 150mm Hole Size 3660mm Height Security Metal Fencing Welded

    150 x 150mm Hole Size 3660mm Height Security Metal Fencing Welded Razor Wire Mesh

    Security Metal Fencing Description:

    Welded razor wire mesh can be installed to achieve the result of threatening and stopping the aggressive perimeter instruders, with straight line structure and sharp ribbon razor blades. Qijie welded razor mesh fence with its special designs make climbing and touching extremely difficult.

    Razor wire type according to diffirent blade shape:

    BTO-12, BTO-15, BTO-18, BTO-22, BTO-30, CBT-60, CBT-65.

    Name

    Security Metal Fencing

    Material

    Galvanized Steel/Stainless Steel

    Type

    BTO-30

    Hole Type

    Square

    Hole Size

    150mmx150mm

    Height

    3.66m

    Length

    30m

    Application

    For Military Field

    Feature

    Long Using Life

    Packing

    Pallet/Roll Packing

    Security Metal Fencing Specification:

    1. Square Hole Size:100mmx100mm,150mmx150mm,200mmx200mm.

    2. Diamond Hole Size:75mmx150mm,100mmx200mm,150mmx300mm.

    Peference

    number

    Thickness

    (mm)

    Wire dia

    (mm)

    Barb length

    (mm)

    Bard width

    (mm)

    Bard spacing

    (mm)

    BTO-12

    0.5±0.05

    2.5±0.1

    12±1

    15±1

    26±1

    BTO-15

    0.5±0.05

    2.5±0.1

    18±1

    15±1

    33±1

    BTO-22

    0.5±0.05

    2.5±0.1

    22±1

    15±1

    34±1

    BTO-30

    0.5±0.05

    2.5±0.1

    30

    18

    45±1

    CBT-60

    0.6±0.05

    2.5±0.1

    60±2

    32±1

    100±2

    CBT-65

    0.6±0.05

    2.5±0.1

    65±2

    21±1

    100±2

    Barbed Tape Wire Specification

    Loop Outside Diameter

    No. of Loops

    Standard Length per Coil

    Type

    Notes

    450mm

    33

    7-8M

    CBT-60.65

    Single coil

    500mm

    56

    12-13M

    CBT-60.65

    Single coil

    700mm

    56

    13-14M

    CBT-60.65

    Single coil

    960mm

    56

    14-15M

    CBT-60.65

    Single coil

    450mm

    56

    8-9m(3 CLIPS)

    BTO-10.12.18.22.28.30

    Cross type

    500mm

    56

    9-10M (3 CLIPS)

    BTO-10.12.18.22.28.30

    Cross type

    600mm

    56

    10-11M(3 CLIPS)

    BTO-10.12.18.22.28.30

    Cross type

    600mm

    56

    8-10M (5 CLIPS)

    BTO-10.12.18.22.28.30

    Cross type

    700mm

    56

    10-12M (5 CLIPS)

    BTO-10.12.18.22.28.30

    Cross type

    800mm

    56

    11-13M (5 CLIPS)

    BTO-10.12.18.22.28.30

    Cross type

    900mm

    56

    12-14M (5 CLIPS)

    BTO-10.12.18.22.28.30

    Cross type

    960mm

    56

    13-15M (5 CLIPS)

    BTO-10.12.18.22.28.30

    Cross type

    980mm

    56

    14-16M (5 CLIPS)

    BTO-10.12.18.22.28.30

    Cross type

    Security Metal Fencing Feature:

    1. It is almost impossible to climb.

    2. High-strength steel core very difficult to cut off.

    3. Powerful security fence barriers neat appearance.

    4. No secondary use, so he will not be stolen.

    5. Simple to install.

    Security Metal Fencing Application:

    Razor wire can be installed in the form of barbed tape wire or concertina coil to walls or fencing. It also can be suitable for industry,agriculture,animal husbandry,dwelling house,plantation or fencing.

    Razor wire is widely used to manufacture the wire fence for a fencing system or security system

    and is applicable in military field,airports fencing,prisons protection,detension houses,government buildings and other national

    security facilities.
