    50mm X 25mm Hole Galvanised Weld Mesh Sheet 6000mm Length Non Rusting

    Ask Lasest Price
    Brand Name : X MESH
    Model Number : X MESH-Mine Mesh-008
    Certification : ISO9001:2015
    Price : USD14.50-58.50/PC
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 58000PCS/WEEK
    Delivery Time : 5-7days
    • Product Details
    • Company Profile

    50mm X 25mm Hole Galvanised Weld Mesh Sheet 6000mm Length Non Rusting

    3mm Wire Diameter with 50mm x 25mm Hole Size Galvanized Welded Mesh Panels

    Galvanized Welded Mesh Introduction:

    Coal mine supporting reinforcing mesh is formed with welded reinforced steel wires/bars.Because of high tensile strength, coal mine supporting mesh is not easy to deform, therefore enhancing the safety factor of coal mines. In addition, the property of anti-corrosion and the strong structure extend the life span.

    Product Name

    Galvanized Welded Mesh

    Material

    Galvanized Steel Wire

    Wire Diameter

    3mm

    Mesh Opening

    50mm x 25mm

    Width

    2400mm

    Length

    6000mm

    Feature

    Firm & Stable

    Application

    for Mine Industrial

    Packing

    Pallet or Wooden Case Packing

    Standard

    AS/NZS4671 Standard

    Galvanized Welded Mesh Specification:

    Mesh Panel Common Specification

    Mesh

    Wire Diameter

    Expressed in Inches

    Millimeters

    Diameter

    Millimeters

    1" × 1"

    25 mm × 25 mm

    11 G - 14 G

    2 mm - 3 mm

    2" × 1"

    50 mm × 25 mm

    8 G - 14 G

    2 mm - 4 mm

    2" × 2"

    50 mm × 50 mm

    8 G - 14 G

    2 mm - 4 mm

    3" × 2"

    75 mm × 50 mm

    6 G - 14 G

    2 mm - 5 mm

    3" × 3"

    75 mm × 75 mm

    6 G - 14 G

    2 mm - 5 mm

    4" × 2"

    100 mm × 50 mm

    4 G - 14 G

    2 mm - 6 mm

    4" × 4"

    100 mm × 100 mm

    4 G - 14 G

    2 mm - 6 mm

    5" × 5"

    125 mm × 125 mm

    4 G - 14 G

    2 mm - 6 mm

    6" × 6"

    150 mm × 150 mm

    4 G - 14 G

    2 mm - 6 mm

    Max Width :2400mm , Max Length : 6000 mm

    Note: Special specifications can be customized.

    Mechanical Properties

    Component

    Strength

    Standard

    Wire

    Tensile 500-750MPa

    AS/NZS4671:2001

    Weld Shear Strength

    ISO15630-2

    Galvanising

    AS/NZS4534-2006

    Galvanized Welded Mesh Feature:

    High tensile strength

    Smooth surface

    Anti-erosion

    anti-aging

    anti-sunburn

    Easy installation.

    Galvanized Welded Mesh Application:

    Coal mine supporting reinforcing mesh is widely used for the security protection of coal mine roadway, tunnel and other facilities.

    It can be installed on the top and both sides of the coal mine roadway, it also can be used in bridges and buildings. It is mainly used for the security protection of coal mine roadway, tunnels and other facilities.

    Used for the loose strata to avoid falling rocks,Applicable to concrete applications,The safety factor has reached the national standard.
