    5.6m Galvanized Welded Mesh Panel High Tensile Strength For Coal Mine

    Ask Lasest Price
    Brand Name : X MESH
    Model Number : X MESH-Mine Mesh-009
    Certification : ISO9001:2015
    Price : USD14.50-58.50/PC
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 58000PCS/WEEK
    Delivery Time : 5-7days
    • Product Details
    • Company Profile

    5.6m Galvanized Welded Mesh Panel High Tensile Strength For Coal Mine

    Galvanized Welded Mesh Wire Panel Sheets with High Tensile Strength type for Coal Mine

    Galvanized Welded Mesh Introduction:

    Coal mine supporting reinforcing mesh is formed with welded reinforced steel wires/bars.Because of high tensile strength, coal mine supporting mesh is not easy to deform, therefore enhancing the safety factor of coal mines. In addition, the property of anti-corrosion and the strong structure extend the life span.

    Product Name

    Galvanized Welded Mesh

    Material

    Galvanized Steel Wire

    Wire Diameter

    4mm

    Mesh Opening

    75mm x 50mm

    Width

    2.4m

    Length

    5.6m

    Feature

    High tensile strength

    Application

    for Coal Mine

    Packing

    Pallet or Wooden Case Packing

    Standard

    AS/NZS4671 Standard

    Galvanized Welded Mesh Specification:

    Mesh Panel Common Specification

    Mesh

    Wire Diameter

    Expressed in Inches

    Millimeters

    Diameter

    Millimeters

    1" × 1"

    25 mm × 25 mm

    11 G - 14 G

    2 mm - 3 mm

    2" × 1"

    50 mm × 25 mm

    8 G - 14 G

    2 mm - 4 mm

    2" × 2"

    50 mm × 50 mm

    8 G - 14 G

    2 mm - 4 mm

    3" × 2"

    75 mm × 50 mm

    6 G - 14 G

    2 mm - 5 mm

    3" × 3"

    75 mm × 75 mm

    6 G - 14 G

    2 mm - 5 mm

    4" × 2"

    100 mm × 50 mm

    4 G - 14 G

    2 mm - 6 mm

    4" × 4"

    100 mm × 100 mm

    4 G - 14 G

    2 mm - 6 mm

    5" × 5"

    125 mm × 125 mm

    4 G - 14 G

    2 mm - 6 mm

    6" × 6"

    150 mm × 150 mm

    4 G - 14 G

    2 mm - 6 mm

    Max Width :2400mm , Max Length : 6000 mm

    Note: Special specifications can be customized.

    Mechanical Properties

    Component

    Strength

    Standard

    Wire

    Tensile 500-750MPa

    AS/NZS4671:2001

    Weld Shear Strength

    ISO15630-2

    Galvanising

    AS/NZS4534-2006

    Galvanized Welded Mesh Feature:

    High tensile strength

    Smooth surface

    Anti-erosion

    anti-aging

    anti-sunburn

    Easy installation.

    Galvanized Welded Mesh Application:

    Slab on Grade reinforcement

    Floor and Walls Systems

    Topping Slabs

    ArchiteFloor and Walls Systemsctural precast wall panels

    Tilt-up construction wall systems

    Shear walls

    Retaining walls

    Mechanically Stabilized Earth (M.S.E.) reinforcement
